What are the main benefits of rectangular connectors?
What are the main benefits of rectangular connectors?
When compared to circular connectors rectangular connectors are generally less expensive,have shorter lead times and are more easily customizable.Rectangular Connectors are also have better grounding system providing more protection against overvoltage and have a visual polarization for easy mating. They can also be easily keyed.
Key advantages for using rectangular connectors over circular includes:
1. Off-the-self modules for easy custom designs for any application.
2. superior space efficiency.
3. more termination option-crimp,solder, screw terminal, others.
4. More locking options-single or double-lever or push button.
5. Ability to connect to other device such as PCB.
6. Greater contact Density Possible.
7. Greater cabling Flexibility- Top,Dual,side or angled cable entry.
8. Surface mount,Panel mount and cable to cable compability.
9.lower cost.
10.Better protection against over voltage.
11. easier Visual mating.
12. Rectangular connectors are more reliable then Circular connectors. while both protect against vibration,the locking elements and seals or rectangular connectors do not allow the peneteration of dust or dirt.
13. rectangular connectors also offers guide pins to protect signal pins and key the connection to prevent mismating a similar connectors .In contrast , the thread of circular connectors are more prone to damage.
14.Rectangular connectors have a solid and reliable earth or ground connection that is first mate. Grounding is a standard features in rectangular connectors for safety reasons.In contrast,a ground connection in circular connectors is not a standard features. it can be added , but it will be a costly option. since there is a limited number of pin configuration, only a specific pin can function as ground and there is only one contact per side.
Thanks for Reading..
